Mean Well Hat Rail Power Supply (DIN-Rail) DR-60-24 24 V/DC 2.5A 60W 1x
Mean Well Hat Rail Power Supply (DIN-Rail) DR-60-24 24 V/DC 2.5A 60W 1 x
- 24 V/DC / 2.5 A
- 60 W Power
- Input -phasigConnection (components): Screw terminals
Related
Product data Mean Well Hat Rail Power Supply
Overview
- 24 V/DC / 2.5 A
- 60 W Power
- Input -phasigConnection (components): Screw terminals
Description
Single-phase primary clocked switching power supply for DIN rail mounting in plastic housing (Step-Shape) , input voltage: 85-264VAC, protection class 2 (without PE)
Properties
can be mounted directly on the DIN rail. closed design, touch-protected screw connections Universal entrance . . . . . . . . Overload protection due to current limitation, auto recovery protected against short-circuit, overload, overvoltage LED display for Power-On Insulation Class II
Keywords
4047976961030, Mean Well, DR-60-24, switching power supply
Technical data
Type: ClockedNumber of outputs: 1 x
Weight: 302.08 g
Output voltage (nom.): 24 V/DC
Brand: Mean Well
Output current (details): 2.5 A
Input voltage (min.): 90 V/AC
Input voltage (max.): 264 V/AC
Number of inputs: 1 x
Height: 56.00 mm
Type: DR-60-24
Herst.-Share: DR-60-24
Output voltage (max.): 24 V/DC
Output current (max.): 2.5 A
Category: DIN-Rail power supply
Length (depth): 78.00 mm
Width: 93.00 mm
Connection: Screw terminal
Performance (details): 60 W
Output: 24 V/DC
